1-100A 额定电流
Current ratings from1to100A
结构紧凑，安装方便
Very compact chassis-mounting design,easy to mount
高性价比
High perating/cost ratio
适合各种通用单相电子设备
Suitable for different kinds of general single-phase equipment
可按不同的插损、工作电流、电压、结构尺寸和端接方式需求定制
Custiomization design for different insertion loss,Rated Current,Rated Vpttsge,Size and Teminal Format requirements
遵循CISPR NO.17/GB 7373标准，插入损耗是在输入/输出均为50Ω的条件下的测量值
--共模(common mode) －差模(differential mode)
Per CISPR NO-17/GB7373 standard,--denotes Common Mode insertion Loss with 50/50Ωtesting condition, and －denotes Differential Mode insertion Loss with 50/50Ω Testing condition
